The World’s Most Advanced
Pure Solid-State Scanning
LiDAR Technology
The World’s Most Advanced
Pure Solid-State Scanning
LiDAR Technology
Scanning LiDAR
with no moving parts
Opsys proprietary technology uses fully addressable VCSEL arrays,
combined with a single chip addressable CMOS SPAD array. Opsys' semiconductor-based solution allows for major cost saving as the non-moving part technology supports automotive standards.
Our Technology
NEMA TS2
Fully certified
Ultra-Fast Scanning
30 FPS post 16/32 averaged
High-Res
0.1 ° down to 0.4° if required
Extreme Reliability
No moving parts
Scalable
Designed for mass production
NDAA
Fully compliant
Flexible Solution
Build any FOV & resolution
Eye Safety
Class 1
Cost-Saving & Competitive
A modular system
Semiconductor-Based
Wafer scale process
Opsys’ multi-wavelength technology enables multiple sensor installation with no interference, while maximizing scan rate and eliminating any dead zones in the full field of view (FOV). The integration of the base sensors is performed by a LiDAR Control Unit (LCU) that provides a single 4D point cloud. The fourth dimension being intensity and ambient data, via an infra-red camera.
This Lego brick approach supports various use cases for different types of applications in addition to the automotive industry. Opsys’ technological capability brings added value to sectors such as Smart Cities, Intelligent Traffic Systems, Security, Robotics and Agriculture. Opsys sensors can improve every aspect of industry - from safety for the workforce as well as efficiency to reduce costs.
Opsys base sensor
Flexibility-Driven Technology
Opsys' unique approach enables the merging of multiple base sensors into an integrated LiDAR system, providing a single point cloud output. This customizable, yet affordable, solution caters to a myriad of use cases across a diverse range of industries.
Opsys Base Sensor
